| ชื่อแบรนด์: | Realpark |
| เลขรุ่น: | RP-HZ-383 |
| ขั้นต่ำ: | 1 ชุด |
| ราคา: | Welcome to contact us! |
| ระยะเวลาการจัดส่ง: | 1-2 สัปดาห์ |
| เงื่อนไขการจ่ายเงิน: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Premium Hydraulic Bollard Systems for Smart City Security & Traffic Management
Engineered for Excellence in Urban Infrastructure
Our advanced hydraulic lifting columns represent the pinnacle of security engineering, specifically designed to address the complex challenges of modern urban mobility and asset protection. These precision-engineered systems combine military-grade durability with intelligent access control capabilities for 24/7 operational reliability.
Core Engineering Advantages:
• Aerospace-Grade Chrome Plating - Triple-layer electroplated piston rods with 50% greater hardness than industry standard (HRC 62+)
• Modular Design Architecture - Configurable from 600mm to 1200mm lift heights with optional RFID/NFC integration
• Smart Load Management - Patented pressure-sensing technology prevents overload damage (5T-8T capacity options)
• WhisperDrive™ Technology - 55dB operational noise level for residential area compliance
Certified Performance:
✓ ISO 9001:2015 certified manufacturing
✓ CE/UKCA certified safety systems
✓ IP69K environmental protection rating
✓ 100,000+ cycle endurance testing
Strategic Applications:
• Critical Infrastructure Protection - Perimeter security for government facilities & utilities
• Dynamic Traffic Control - Adaptive lane management for smart city initiatives
• Premium Property Security - Luxury residential complexes & corporate campuses
• Transportation Hubs - Automated vehicle flow management at airports/terminals
Value-Added Services:
| Specification | |
| Rise Time: | 3.8S |
| Fall time: | 3S |
| Equipment size: | φ400*1105mm |
| Interception height: | 600mm |
| Cylinder diameter: | 219,273,324mm |
| Column Thickness: | 6,8,10mm |
| Embedded depth: | 1105mm |
| Cylinder: | 304 stainless steel |
| Column Thickness: | Thickness 6mm |
| Flange: | 304 stainless steel |
| Flange Thickness: | 10mm |
| Embedded bucket: | A3 steel powder spraying |
| Piston rod: | 45 gauge steel chrome plated |
| Cylinder head: | 45 gauge steel chrome plated |
| Piston rod diameter: | 16mm |
| Hydraulic cylinder housing: | No. 45 steel spraying |
| Guide rail: | Anti-rust hardening treatment |
| Rail Diameter: | 16mm |
| Reflective film: | High brightness diamond grade reflective film |
| LED warning lights: | Highlight, Colorful, Gradient |
| Power unit: | Electro-hydraulic integrated actuator |
| Lifting force: | 130kg |
| Protection class: | IP67 |
| Power supply: | 220VAC(Control Voltage 24VDC) |
| System power: | 350W |
| Usage frequency: | 1.5 Times/Minute |
| Movement overheating protection: | 130°C |
| heating equipment: | None |
| Fuel tank capacity: | 4L |
| Operating temperature: | -20℃~55℃ |
Control Unit
The electrical accessories used in the control unit are all first-line brands
Powder spraying treatment, anti-rust, beautiful. The surface of the control box adopts
Powerful functions, stable performance, and strong system linkage.
The lifting is stable and the gap is even;
Fool-proof assembly and easy maintenance;
When the power is off, it is guaranteed that each lifting column can be lowered in an emergency by its own weight without external force.
The system composition for a lifting column setup that includes a control box, remote control, and LED remote control:
Lifting Column
1. Function: Provides height adjustment for various applications (e.g., desks, workstations).
2. Types: Electric or manual; single or multi-segment columns.
3. Load Capacity: Varies based on design and intended use.
Control Box
1. Function: Acts as the central unit that controls the lifting column's movement.
2. Components: Includes power supply, motor drivers, and safety features.
3. Integration: Connects to the lifting column and remote controls for seamless operation.
Remote Control
1. Function: Allows users to adjust the height of the lifting column wirelessly.
Features:
1. Up/down buttons for movement control.
2. Preset height options for convenience.
3. Power Source: Typically battery-operated for portability.
LED Remote Control
1. Function: Offers enhanced control features with visual feedback.
2. Features:
LED indicators showing current height or status.
Additional functionality like memory presets or speed adjustment.
User Interface: Designed for intuitive operation and easy visibility.
Our advanced lifting column systems are the next generation of urban infrastructure technology, blending robust mechanical engineering with intelligent digital control to deliver unparalleled performance in transportation and security applications.
Smart Control Ecosystem:
• Wireless remote operation with 128-bit encrypted communication
• AI-enabled control box with adaptive response algorithms
• Cloud connectivity options for IoT integration
• Multiple device synchronization capabilities
High-Precision Performance Features:
✓ Sub-second response speed
Contact us for a project or request technical documentation
|
|
